Phoenix Audio DRS-EQ 500 Series EQ

Phoenix Audio DRS-EQ 500 Series EQ

$769.00
$769.00
Skip to product information
Phoenix Audio DRS-EQ 500 Series EQ
  • Phoenix Audio DRS-EQ 500 Series EQ
  • Phoenix Audio DRS-EQ 500 Series EQ
Phoenix Audio

Phoenix Audio DRS-EQ 500 Series EQ

MFR# DRS-EQ/500

500 Series equalizer

Product No Longer Available

Need help finding a different option? We can help.

Experts At Your Service

Have a question? Our Audio Consultants and Technicians have years of real-world experience and are ready to help.

Call now

Product Description

Phoenix Audio DRS-EQ-500 Specifications:
  • Class A (DSOP-2) Output specs. Frequency response: 20Hz to 20kHz +- 0.5dB
  • Maximum Output Level: +26dBu @ 1kHz
  • Noise: -90dB @ 20Hz to 20kHz.
  • Phoenix Audio’s unique Class A, buffer DSblip stage.
  • Input level range: -10dBu to +10dBu
  • Self-contained on-board “boost” PSU.
  • Gain Meter: LED Metering. (Green = -2dB, +4dbu & +10dbu Yellow = +13dB, Red = +16dbu.
  • High Pass Filter: Roll-off starts at 80Hz @ 12dB per Octave.
  • Gyratory-based EQ Frequency Centres: (4 Bands) High – 15K, 10K, Hi Mid – 6K, 3K, 1K6, Low Mid – 800Hz, 400Hz, 200Hz, Low – 130Hz, 80Hz, 40Hz
  • EQ Cut/Boost Levels: 16dB Cut/Boost Per Band, all EQ bands are stepped/detented to 21 positions for easy recall & stereo operations for mastering or the mix bus.
  • DRS-EQ/500 has an overall output level with 15db of additional gain even when the EQ is in bypass, allows the output fader to be used to drive the output stage & transformer to color & saturate your sound, again even when the EQ is in bypass.
