AML VPR 500 Rack with 54F50 and ez1073-500 Modules

MFR# AML-16-025

Two compressor/limiter modules and two mic preamp/EQ modules in a 500-series rack

Product No Longer Available

Need help finding a different option? We can help.

Experts At Your Service

Have a question? Our Audio Consultants and Technicians have years of real-world experience and are ready to help.

Call now

Product Description

The AML VPR 500 Rack with 54F50 and ez1073-500 Modules bundle consists of two AML 54F50 compressor/limiter modules, and two AML ez1073-500 mic preamp/eq modules loaded into a VPR 500 rack.

AML 54F50

The AML 54F50 is a Class A, compressor and limiter module which occupies three slots in a 500 series rack. Fully populated with Carnhill transformers to achieve its distinctive classic sound, this high-end hand-built British module provides an affordable solution for the modern cost conscious studio.

ez1073‐500

The AML ez1073-500 is a Class A, mic pre-amp, line amp and EQ/Filter module which occupies two slots in a 500 series rack. Fully populated with Carnhill transformers and inductors to achieve its distinctive classic sound, this high-end hand-built British module provides an affordable solution for the modern cost conscious studio.

Features:

  • Classic 3 stage (Class A) amplifier design
  • All discrete component (no surface mount devices)
  • Entirely hand assembled and tested in England to exacting quality standards
  • Mic Input: Carnhill transformer balanced (Classic VTB9045) +10dB to +65dB gain, rotary switchable in 5dB steps and switchable 300/1200 Ohm impedance input
  • Line Input: Carnhill transformer balanced (Classic VTB9046) - 20dB to +20dB, rotary switchable in 4dB steps (centre 0dB), 10k Input Impedance
  • Line Output: Carnhill transformer balanced (Classic full size output transformer)
  • EQ/Filter Stage: 3 inductor (Class A) amplifier design
  • HF (12kHz) +/- 16dB gain continuously variable
  • MF (switchable; 360Hz, 700Hz, 1.6kHz, 3.2kHz, 4.8kHz & 7.2kHz) +/- 16dB gain continuously variable
  • LF (switchable; 35Hz, 60Hz, 110Hz & 220Hz) +/- 16dB gain continuously variable
  • Low Pass Filter (switchable; 50Hz, 80Hz, 160Hz & 300Hz) -18dB per Octave
  • Phantom and polarity switches
  • The XLR behind the left hand side is the Mic Input
  • The XLR behind the right hand side is the Line Input
  • The output is duplicated on both of the output XLRs
  • Stainless steel chassis
  • Total current consumption 110mA (per unit)
  • For use in API (and compatible) Lunchbox and VPR500 racking systems
